Features

• DUAL-CAN TELEMATICS GATEWAY FOR MODERN FLEETS

  Two CAN-FD/J1939 channels plus GNSS give you precise, real-time visibility into vehicle health, usage, and location across light-, medium-, and heavy-duty equipment.

• RICH TRACKING & TELEMETRY SIGNALS

  GPS/GNSS reporting with motion, tow, idle, geofence, and engine-state events so you can see how, where, and when assets are being used.




• DRIVER BEHAVIOR & SAFETY INSIGHTS

  Detects over-speed, over-RPM, hard braking, and aggressive acceleration events to support coaching, risk reduction, and safer driving policies.




• GEOFENCING & THEFT PROTECTION

  Entry/exit monitoring with unauthorized-movement and theft alerts—backed by an internal rechargeable battery that keeps reporting through power loss or tampering.




• BLE 5.2 SENSOR AND TRAILER AWARENESS

  Passive BLE advertisement monitoring for nearby beacons, trailers, tags, and sensors so you can extend visibility beyond the vehicle to connected assets.

• OTA UPDATES & EVENT REPORTING AT SCALE

  Secure over-the-air updates for main and recovery firmware plus custom scripts, with SMS- and UDP-based auto-reporting for key events like location, power loss, and DTCs.

• FEATURES & PERFORMANCE

  • →

    Tracking & Telemetry: GPS + GNSS with motion, tow, idle, geofence, and engine-state reporting
  • →

    Driver Behavior: Over-speed, over-RPM, hard braking/acceleration
  • →

    Geofencing: Entry/exit detection, triggers theft/stolen alerts
    BLE Beacon Monitoring: Passive BLE 5.2 advertisement monitoring (trailers, tags, sensors)
  • →

    Firmware Management: OTA updates (Main, Recovery, Scripts)
  • →

    Event Reporting: SMS, UDP-based auto reports (location, power loss, DTCs)
  • →

    Backup Power: Internal rechargeable battery for theft recovery & offline event capture

• CONNECTIVITY & POSITIONING

  • →

    Cellular: LTE Cat 1 (Bands: 2, 4, 5, 12, 13, 66)
  • →

    GNSS: GPS, GLONASS, Galileo, BeiDou, QZSS
  • →

    Accuracy: 2.5m
  • →

    Assisted GNSS: Yes
  • →

    Cold Start: <30s
  • →

    Hot Start: <2s
  • →

    Bluetooth: BLE 5.2
  • →

    Antennas: Internal (Optional SMA connectors for external variant)
  • →

    Communication Protocols: UDP, SMS, FTP

• I/O & INTERFACES

  • →

    CAN FD: 2× isolated channels (J1939 supported)
  • →

    Digital Inputs: Up to 6
  • →

    Digital Outputs: Up to 2
  • →

    Analog Inputs: 1
  • →

    Other Interfaces: J1708, J1850, KWP, ISO-9141, USB, Ignition Sense
  • →

    Diagnostic Port: USB
  • →

    LEDs: 4 (status indicators + programmable diagnostics)

• SOFTWARE & PLATFORM

  • →

    Scripting Engine: Yes (event-based logic)
  • →

    Report Queue: 15,000 reports
  • →

    User Customization: Digital I/O configuration, script logic, BLE beacon scan settings
  • →

    OTA Support: Main, Recovery, Script, Config
  • →

    CLI: Yes (CDC-ACM over USB)

• POWER & ENVIRONMENTAL

  • →

    Input Voltage: 12V / 24V systems
  • →

    Power Modes: <1mA (Sleep), Active mode varies with load
  • →

    Internal Battery: 1150mAh Li-ion
  • →

    Operating Temperature: –40°C to +85°C
  • →

    Enclosure: IP69K rated
  • →

    Shock & Vibration: SAE J1455, HALT tested to 30G

• FORM FACTOR

  • →

    Dimensions: 155mm × 75mm × 31mm
  • →

    Weight: 344g
  • →

    Mounting: Zip ties, screws, adhesive mount
  • →

    Connector: Ruggedized 16-pin automotive-grade

• CERTIFICATIONS & COMPLIANCE

  • →

    Carrier Certifications: AT&T LTE, PTCRB
  • →

    Regulatory: FCC / IC, RoHS
  • →

    Transport: UN 38.3, SAE J1455 shock/vibration
  • →

    Ingress Protection: IP69K certified
  • →

    ESD / EMC: CISPR 25, radiated/conducted emissions compliant
